How to Make a GPS Tracker with Raspberry Pi Step by Step Guide

4 Mins Read GPS Tracker

In this guide, you’ll learn how to make a GPS tracker with Raspberry Pi from scratch. We cover all steps, from setting up your Raspberry Pi to connecting the GPS module and coding the tracker. This project is perfect for beginners who want a hands-on introduction to GPS technology and Raspberry Pi.

Key Takeaways

  • Understand GPS basics: Learn how GPS modules communicate with Raspberry Pi for location tracking.
  • Hardware setup: Discover which components to use and how to connect them properly.
  • Software installation: Step-by-step instructions to install necessary libraries and tools.
  • Programming the tracker: Write Python code to read GPS data and display location info.
  • Data logging and visualization: Save GPS coordinates and visualize routes effectively.
  • Troubleshooting tips: Solve common issues related to hardware and software.
  • Expandability: Ideas for improving and customizing your GPS tracker.

How to Make a GPS Tracker with Raspberry Pi Step by Step Guide

Are you interested in tracking locations using a Raspberry Pi? This guide will show you how to make a GPS tracker with Raspberry Pi easily. Whether you want to track a vehicle, a pet, or just experiment with GPS technology, this project will walk you through every step. You’ll learn about the hardware, software, and coding needed to get your GPS tracker up and running.

What You Will Need

  • Raspberry Pi (any model with GPIO pins, e.g., Raspberry Pi 3 or 4)
  • GPS Module (such as the Neo-6M GPS module)
  • MicroSD card with Raspberry Pi OS installed
  • Power supply for Raspberry Pi
  • Jumper wires (female to male)
  • Breadboard (optional, for easier wiring)
  • Internet connection for software installation
  • A monitor, keyboard, and mouse (or SSH setup for headless use)

Step 1: Set Up Your Raspberry Pi

Install Raspberry Pi OS

First, ensure your Raspberry Pi has the latest Raspberry Pi OS installed. You can download the OS image from the official Raspberry Pi website and flash it onto your microSD card using tools like Raspberry Pi Imager or Balena Etcher.

How to Make a GPS Tracker with Raspberry Pi Step by Step Guide

Visual guide about How to Make a GPS Tracker with Raspberry Pi Step by Step Guide

Image source: content.instructables.com

Connect to the Internet

After booting up your Raspberry Pi, connect it to the internet via Wi-Fi or Ethernet. This connection is essential to install necessary software packages.

Update Your System

Open the terminal and run the following commands to update your system:

  • sudo apt update
  • sudo apt upgrade -y

Step 2: Connect the GPS Module to Raspberry Pi

Identify the GPS Module Pins

Your GPS module will have pins typically labeled VCC, GND, TX, and RX. VCC is power, GND is ground, TX is transmit, and RX is receive.

Wiring the GPS Module

Use jumper wires to connect your GPS module to the Raspberry Pi GPIO pins:

  • GPS VCC to Raspberry Pi 3.3V (Pin 1)
  • GPS GND to Raspberry Pi Ground (Pin 6)
  • GPS TX to Raspberry Pi RX (GPIO Pin 15, physical Pin 10)
  • GPS RX to Raspberry Pi TX (GPIO Pin 14, physical Pin 8)

Note: Some GPS modules operate at 3.3V logic level compatible with Raspberry Pi. Confirm your module voltage to avoid damage.

Enable Serial Port

By default, the Raspberry Pi’s serial port is used for console access. To use it for GPS data, disable the console login on the serial port:

  • Run sudo raspi-config
  • Select Interfacing Options > Serial
  • Choose No when asked to enable the login shell over serial
  • Choose Yes to enable the serial port hardware
  • Finish and reboot your Raspberry Pi

Step 3: Install Required Software

Install GPSD and GPSD Clients

GPSD is a daemon that handles GPS data on Linux systems. Install it with:

  • sudo apt install gpsd gpsd-clients python3-gps -y

Configure GPSD

Edit the GPSD default configuration file to set the GPS device:

  • sudo nano /etc/default/gpsd

Change or add the following lines:

  • DEVICES="/dev/serial0"
  • GPSD_OPTIONS="-n"
  • USBAUTO="false"
  • GPSD_SOCKET="/var/run/gpsd.sock"

Save and exit (Ctrl+X, Y, Enter). Restart GPSD:

  • sudo systemctl restart gpsd

Step 4: Test the GPS Module

Check GPS Data Stream

Run the following command to see raw GPS data:

  • cgps -s

This opens a terminal interface showing satellite info and your current coordinates. If you see data streaming, your GPS module works!

Troubleshooting GPS Signal

  • Make sure your GPS antenna has a clear view of the sky.
  • Wait a few minutes for the module to lock onto satellites.
  • Verify wiring connections.

Step 5: Write Python Code to Read GPS Data

Create Your Python Script

Open a new Python file:

  • nano gps_tracker.py

Sample Python Code

Use the following code to read GPS data and print latitude and longitude:

import gps


session = gps.gps(mode=gps.WATCH_ENABLE)


try:

    print("Waiting for GPS data...")

    while True:

        report = session.next()

        if report['class']
